All converters
CAD to Excel converters for Revit®, IFC, DWG and DGN, side by side
Six converters, one output shape: each element becomes a row, each property a column. They run offline, without Autodesk or Bentley software.
Comparison of the six converters
| Converter | Reads | Writes | Command line / Linux | Smoke test10 files, mean s | Download |
|---|---|---|---|---|---|
| Revit to Excelno Revit needed | RVTRevit 2015 to 2026, RVT and RFA | XLSX DAE PDF | RvtExporter.exeddc-rvtconverter | 10/10, 148 s | 210 MB download, Revit to Excel |
| Revit to IFCno Revit needed | RVTRevit 2015 to 2026 | IFC | RVT2IFCconverter.exeddc-rvt2ifcconverter | 10/10, 220 s | 237 MB download, Revit to IFC |
| Revit to DAEno Revit needed | RVTRevit 2015 to 2026, RVT and RFA | DAE XLSX | RvtExporter.exeddc-rvtconverter | same run as Revit to Excel | 210 MB download, Revit to DAE |
| IFC to Excelno a BIM tool needed | IFCIFC 2x3 to 4.3, not IFC4X3_RC2 | XLSX DAE | IfcExporter.exeddc-ifcconverter | 10/10, 24.6 s | 74 MB download, IFC to Excel |
| DWG to Excelno AutoCAD needed | DWGDWG 1983 to 2026 | XLSX PDF | DwgExporter.exeddc-dwgconverter | 10/10, 27.6 s | 78 MB download, DWG to Excel |
| DGN to Excelno MicroStation needed | DGNDGN v7 and v8 | XLSX | DgnExporter.exeddc-dgnconverter | 10/10, 4.0 s | 78 MB download, DGN to Excel |
Build v28052026, Windows 10/11 x64; Linux packages from the DDC APT repository. Smoke test: version 18.4.1, Windows 11, 2026-05-28; method and limits on the benchmark page. Community licence: personal and research use.
The same table shape, whatever the source
Real excerpts from two converters. Revit rows carry parameters by name; DWG rows are keyed by the entity handle.
| ID | Category | Type | Level | Area | Volume | |
|---|---|---|---|---|---|---|
| 176804 | OST_Floors | Generic 150mm | Level 1 | 105.906 | 15.886 | |
| 198694 | OST_Walls | SIP 202mm Wall - conc clad | Level 2 | 22.355 | 4.516 | |
| 198749 | OST_Walls | Wall - Timber Clad | Level 1 | 6.010 | 1.214 | |
| 418183 | OST_Floors | Generic 300 | Level 2 | 100.493 | 30.148 | |
| 422466 | OST_Doors | 800 x 2100 | Level 1 | 2.965 | 0.109 | |
| 457479 | OST_Windows | Standard | Level 2 | 5.519 | 0.154 | |
| 2,490 more rows, 1,021 more columns in the file | ||||||
| ID | Description | Handle | Layer | Linetype | Length | Area | Closed | |
|---|---|---|---|---|---|---|---|---|
| 584 | <AcDbPolyline> | [248] | door | ByLayer | 1700 | 40000 | true | |
| 597 | <AcDbPolyline> | [255] | door | ByLayer | 1700 | 40000 | true | |
| 610 | <AcDbPolyline> | [262] | door | ByLayer | 1700 | 40000 | true | |
| 623 | <AcDbPolyline> | [26F] | door | ByLayer | 1700 | 40000 | true | |
| 657 | <AcDbPolyline> | [291] | window | ByLayer | 4000 | 300000 | false | |
| 658 | <AcDbPolyline> | [292] | vent | ByLayer | 2225 | 75000 | false | |
| 974 more rows, 403 more columns in the file | ||||||||
Which one do I need?
Pick the file you have and the result you want. Unsupported pairs say why instead of sending you to the wrong download.
Not supported
- Downgrading an RVT to an older Revit; see Revit versions.
- RVT to DWG, DWG to IFC, DGN to IFC.
- 3D geometry from DWG or DGN.
- Converting in a browser. Everything runs on your machine.
Find your converter
Choose input and outputBy downloading you agree to the Terms of Use and EULA. Community licence: personal and research use.
Other ways to use the same converters
- DDC Excel add-in
- Opens RVT, IFC and DWG data inside Excel and adds QTO, parameter checks, duplicates and dashboards.
- n8n workflows
- Nine MIT-licensed workflows that call the converters, validate the output and write reports.
- New generation (preview)
- Our own DWG reader, tested on 504 real drawings with 95.9 % of records decoded. Not yet released.
- Guides
- Commands, options and scripts per format, including batch conversion with Python.
Converted on the download site in one year: RVT 53,321, DWG 45,687, IFC 29,542, DGN 2,567 files (as of 2026-10-17). The DWG sample in Fig. 2 has 980 rows.
Questions about choosing a converter
Is there one converter for all CAD formats?
There is one converter per input format, with the same output shape: one row per element, one column per property. Install only the ones you need; Revit to Excel and Revit to DAE ship in the same zip.
Can you convert RVT to DWG?
No. We do not convert RVT to DWG or between other CAD formats. We extract data to Excel and write IFC and DAE.
Which converter gives 3D geometry?
The Revit and IFC converters write DAE (Collada) with element IDs that match the Excel rows. DWG and DGN give data only; DWG also writes PDF drawings.
Can I run them on a server?
Yes. Each converter has a command line and a Linux package. Server and batch deployment for a company needs a commercial licence.
